SOLVED CS614 GDB Solution and Discussion

[zaasmi]

Total Marks 5
Starting Date Monday, July 15, 2019
Closing Date Tuesday, July 16, 2019
Status Open
Question Title GDB - CS614
Question Description
Scenario

“Choice Restaurant” is a chain of restaurants having five branches across the country. This restaurant typically deals in fast food and has 40 to 100 customers a day in each branch.

The Management of this company has introduced an Online Transaction Processing (OLTP) system to handle the daily transactions. The Management is very concerned for cutting up the cost and attain customer satisfaction, therefore currently there is only one computer system per branch which is handling all the computing tasks (including transaction processing) but in future they have plans to induce DSS.

To speed up the online transaction processing the database manager is compelling the management to implement parallelism for this OLTP system during business hours for daily sales calculations.

Management is yet to decide that whether they should invest on the parallelism or not.

GDB Question:

Keeping the above scenario in mind do you think that implementing parallelism in above situation is a good option? Justify your answer with appropriate reason(s) in either case.

GDB Answer Template:

Choice: Parallelism used or not

Points of Justification:

Point 1:

Point 2:

Important Notes:

NO GDB is accepted via e-mail in any case
Lengthy replies of GDB will cause in deduction of marks. So you write your answer precisely within 3 to 5 lines in 2 points along with choice.
If you would not mention your choice at start of your answer, your GDB points would not be marked.

[moaaz]

Introduction to Parallel Execution
Parallel execution enables the application of multiple CPU and I/O resources to the execution of a single database operation. It dramatically reduces response time for data-intensive operations on large databases typically associated with a decision support system (DSS) and data warehouses. You can also implement parallel execution on an online transaction processing (OLTP) system for batch processing or schema maintenance operations such as index creation. Parallel execution is sometimes called parallelism. Parallelism is the idea of breaking down a task so that, instead of one process doing all of the work in a query, many processes do part of the work at the same time. An example of this is when four processes combine to calculate the total sales for a year, each process handles one quarter of the year instead of a single process handling all four quarters by itself. The improvement in performance can be quite significant. Parallel execution improves processing for:

Queries requiring large table scans, joins, or partitioned index scans

Creation of large indexes

Creation of large tables (including materialized views)

Bulk insertions, updates, merges, and deletions

You can also use parallel execution to access object types within Oracle Database. For example, you can use parallel execution to access large objects (LOBs).

If the necessary parallel server processes are not available for parallel execution, a SQL statement is queued when the parallel degree policy is set to automatic. After the necessary resources become available, the SQL statement is dequeued and allowed to execute. The parallel statement queue operates as a first-in, first-out queue by default. If the query in front of the queue cannot be scheduled, none of the queries in the queue can be scheduled even if resources are available in the system to ensure that the query at the head of the queue has adequate resources. However, if you configure and set up a resource plan, then you can control the order in which parallel statements are dequeued and the number of parallel servers used by each workload or consumer group. For information, refer to “Managing Parallel Statement Queuing with Resource Manager”.

This section contains the following topics:

When to Implement Parallel Execution

When Not to Implement Parallel Execution

Fundamental Hardware Requirements

Operations That Can Use Parallel Execution

When to Implement Parallel Execution
Parallel execution benefits systems with all of the following characteristics:

Symmetric multiprocessors (SMPs), clusters, or massively parallel systems

Sufficient I/O bandwidth

Underutilized or intermittently used CPUs (for example, systems where CPU usage is typically less than 30%)

Sufficient memory to support additional memory-intensive processes, such as sorting, hashing, and I/O buffers

If your system lacks any of these characteristics, parallel execution might not significantly improve performance. In fact, parallel execution may reduce system performance on overutilized systems or systems with small I/O bandwidth.

The benefits of parallel execution can be seen in DSS and data warehouse environments. OLTP systems can also benefit from parallel execution during batch processing and during schema maintenance operations such as creation of indexes. The average simple DML or SELECT statements that characterize OLTP applications would not experience any benefit from being executed in parallel.

When Not to Implement Parallel Execution
Parallel execution is not typically useful for:

Environments in which the typical query or transaction is very short (a few seconds or less).

This includes most online transaction systems. Parallel execution is not useful in these environments because there is a cost associated with coordinating the parallel execution servers; for short transactions, the cost of this coordination may outweigh the benefits of parallelism.

Environments in which the CPU, memory, or I/O resources are heavily utilized.

Parallel execution is designed to exploit additional available hardware resources; if no such resources are available, then parallel execution does not yield any benefits and indeed may be detrimental to performance.

Fundamental Hardware Requirements
Parallel execution is designed to effectively use multiple CPUs and disks to answer queries quickly. It is very I/O intensive by nature. To achieve optimal performance, each component in the hardware configuration must be sized to sustain the same level of throughput: from the CPUs and the Host Bus Adapters (HBAs) in the compute nodes, to the switches, and on into the I/O subsystem, including the storage controllers and the physical disks. If the system is an Oracle Real Application Clusters (Oracle RAC) system, then the interconnection also has to be sized appropriately. The weakest link is going to limit the performance and scalability of operations in a configuration.

It is recommended to measure the maximum I/O performance a hardware configuration can achieve without Oracle database. This measurement can be used as a baseline for the future system performance evaluations. Remember, it is not possible for parallel execution to achieve better I/O throughput than the underlying hardware can sustain. Oracle Database provides a free calibration tool called Orion, which is designed to measure the I/O performance of a system by simulating Oracle I/O workloads. A parallel execution typically performs large random I/Os.

Operations That Can Use Parallel Execution
You can use parallel execution for any of the following:

Access methods

Some examples are table scans, index fast full scans, and partitioned index range scans.

Join methods

Some examples are nested loop, sort merge, hash, and star transformation.

DDL statements

Some examples are CREATE TABLE AS SELECT, CREATE INDEX, REBUILD INDEX, REBUILD INDEX PARTITION, and MOVE/SPLIT/COALESCE PARTITION.

You can typically use parallel DDL where you use regular DDL. There are, however, some additional details to consider when designing your database. One important restriction is that parallel DDL cannot be used on tables with object or LOB columns.

All of these DDL operations can be performed in NOLOGGING mode for either parallel or serial execution.

The CREATE TABLE statement for an index-organized table can be run with parallel execution either with or without an AS SELECT clause.

Different parallelism is used for different operations. Parallel CREATE (partitioned) TABLE AS SELECT and parallel CREATE (partitioned) INDEX statements run with a degree of parallelism (DOP) equal to the number of partitions.

DML statements

Some examples are INSERT AS SELECT, UPDATE, DELETE, and MERGE operations.

Parallel DML (parallel insert, update, merge, and delete operations) uses parallel execution mechanisms to speed up or scale up large DML operations against large database tables and indexes. You can also use INSERT … SELECT statements to insert rows into multiple tables as part of a single DML statement. You can ordinarily use parallel DML where you use regular DML.

Although data manipulation language usually includes queries, the term parallel DML refers only to inserts, updates, merges, and deletes done in parallel.

Parallel query

You can run queries and subqueries in parallel in SELECT statements, plus the query portions of DDL statements and DML statements (INSERT, UPDATE, DELETE, and MERGE).

Miscellaneous SQL operations

Some examples are GROUP BY, NOT IN, SELECT DISTINCT, UNION, UNION ALL, CUBE, and ROLLUP, plus aggregate and table functions.

SQL*Loader

You can use SQL*Loader in parallel execution where large amounts of data are routinely encountered. To speed up your load operations, you can use a parallel direct-path load as in the following example:

sqlldr CONTROL=LOAD1.CTL DIRECT=TRUE PARALLEL=TRUE
sqlldr CONTROL=LOAD2.CTL DIRECT=TRUE PARALLEL=TRUE
sqlldr CONTROL=LOAD3.CTL DIRECT=TRUE PARALLEL=TRUE
You provide your user Id and password on the command line. You can also use a parameter file to achieve the same result.

An important point to remember is that indexes are not maintained during a parallel load.

Source

[moaaz]

1. Useful for operations that access significant amounts of data.
2. Useful for operations that can be implemented independent of each other “Divide-&-Conquer”

Parallel execution improves processing for:

Large table scans and joins
Creation of large indexes
Partitioned index scans
Bulk inserts, updates, and deletes
Aggregations and copying
